# SICP Goodness - What is Meant by Data? (II)

Just a little bit of lambda calculus

Do you think Computer Science

equalsbuilding websites and mobile apps?Are you feeling that you are doing

repetitiveandnot so intelligentwork?Are you feeling a bit

sickaboutreading manualsandcopy-pastingcode and keeppoking arounduntil it worksall day long?Do you want to understand the

soulofComputer Science?If yes,

read SICP!!!

This is the second part of a two part series, you can find the first part here.

The main topic of this post is `Church Encoding`

.

# Boolean

How to build `Boolean`

value *true* and *false* using only functions?

Let’s take a look at the general idea of a boolean.

`if bool ? first : second`

So here we see that the practical meaning of a boolean is to make choices. The program does not care whether something is really true or not, it only need to use it to make choices.

The above example code says that if `bool`

is TRUE, it returns `first`

, else returns `second`

. This sounds very familiar, yes, they are `K`

and `KI`

. So actually we already have boolean functions.

```
(define T K)
(define F KI)
```

# Not

The `Not`

function takes `T`

returns `F`

and vice versa.

```
;; NOT := λp. p F T
(define (NOT p) ((p F) T))
```

Just try the NOT function, it actually works.

There is another way to think about `NOT`

. `T`

is a function that returns the first argument, and `F`

is function that returns the second argument. Imagine after applying `NOT`

to them, `T`

will return the second argument and `F`

will return the first argument. So `NOT`

changes the behavior of `T`

and `F`

, as if the order of the arguments have been switched. Emmm, what function switches arguments?

`C`

. So `C`

is `NOT`

.

# And

```
;; AND := λpq. p q p
(define (AND p)
(lambda (q)
((p q) p)))
```

Try all 4 combinations and prove that this is actually AND.

# Or

Similar to `AND`

, `OR`

is:

```
;; OR := λpq. p p q
(define (OR p)
(lambda (q)
((p p) q)))
```

If we ignore the `q`

here, then `OR`

becomes `M`

! Actually they behave the same way. You can try it yourself.

OK, enough logic, let’s talk about numbers.

# Numbers

To define numbers as function, we need to make some slight changes. Instead of one two three, we are using once twice thrice. Because of reasons ;)

```
;; N1 := λfa. f a
(define N1
(lambda (f)
(lambda (a) (f a))))
```

`N1`

is a function that takes `f`

and `a`

and calls `f`

**once** on `a`

.

And `N2`

can be defined similarly as:

```
;; N2 := λfa. f (f a)
(define N2
(lambda (f)
(lambda (a) (f (f a)))))
```

`N2`

calls `f`

**twice** on `a`

.

Let’s also define `N3`

here.

```
;; N3 := λfa. f (f (f a))
(define N3
(lambda (f)
(lambda (a) (f (f (f a))))))
```

I think you get the idea, our number system is defined by how many times we apply a function `f`

to an argument `a`

.

What is 0? It is calling `f`

on `a`

zero times.

```
;; N0 := λfa.a
(define N0
(lambda (f)
(lambda (a) a)))
```

Wait, `N0`

looks familiar, it is `KI`

or `F`

.

Also look back at `N1 := λfa. f a`

, if we see `f a`

as together, then `N1`

is `I`

.

So 0 is false and 1 is identity, this should’ve put a smile on your face.

# SUCC

A `SUCC`

function will add 1 to a given number.

```
SUCC N1 = N2
SUCC N2 = N3
SUCC (SUCC N1) = N3
...
```

It is not very straightforward to implement `SUCC`

, so let’s take it slowly.

First, `SUCC`

should take a church number `n`

and returns a new church number.

`SUCC := λnfa.??`

The new church number is simply calling `f`

once more. So we can just call `f`

`n`

times on `a`

first, and then call `f`

on the result.

`SUCC := λnfa.f(nfa)`

```
(define SUCC
(lambda (n)
(lambda (f)
(lambda (a)
(f((n f) a))))))
```

Now to verify all these, let’s translate the church numbers into real numbers.

The function `to_real_numbers`

takes a church number `n`

andf calls it with `plus one`

funcation as `f`

and 0 as `a`

. For example, `N2`

now means increase 1 twice on 0.

```
(define to_real_number
(lambda (n)
((n (lambda (x) (+ x 1))) 0)))
```

# Blue Bird

Next, let’s introduce another bird: Blue Bird.

`B`

acts like a function pipeline, or function composition.

Apply the outer most function with `a`

, take the result and pass it as a parameter for inner function, and keep doing this until there is no inner function anymore.

```
(define B
(lambda (f)
(lambda (g)
(lambda (a)
(f (g a))))))
```

For example

```
;; the pipeline is N1 -> N2 -> 2
(((B to_real_number) SUCC) N1)
```

# ADD

How to implement `ADD`

?

```
(ADD N0 N3) = N3
(ADD N1 N3) = (SUCC N3)
(ADD N2 N3) = (SUCC (SUCC N3))
```

We can see add `n`

to `a`

can be seen as apply n times `SUCC`

on `a`

.

```
;; ADD := λnk.n SUCC k
(define ADD
(lambda (n)
(lambda (k)
((n SUCC) K))))
```

# MULT

Again let’s use the example of `(MULT N2 N3)`

.

We know the result should be `N6`

, which means apply some `f`

6 times on some `a`

.

But we can also say that it applies `f`

3 times `twice`

.

```
;; MULT := λnkf.n(kf)
(define MULT
(lambda (n)
(lambda (k)
(lambda (f)
(n (k f))))))
```

Wait a moment, look at the definition above, it is identical to `B`

. So `MULT`

is actually `B`

!

I think we have come quite far. If you now look back at the Ex.2.6 mentioned in Part I, we not only can answer how to implement `ADD`

, we know how to implement `MULT`

too!
