# SICP Goodness - What is Meant by Data? (I)

Just a little bit of lambda calculus

Do you think Computer Science

equalsbuilding websites and mobile apps?Are you feeling that you are doing

repetitiveandnot so intelligentwork?Are you feeling a bit

sickaboutreading manualsandcopy-pastingcode and keeppoking arounduntil it worksall day long?Do you want to understand the

soulofComputer Science?If yes,

read SICP!!!

Let’s begin by asking the question: *What is data?* You may say that *data* is numbers, characters, strings, pairs, lists, maps, sets and so on. Then, *what is procedure?*. Well a procedure is a function that can be called with(out) parameters.

What if I tell you that data can be procedures?

For me, the first really mind boggling example in the book is this:

```
(define (pair x y)
(define (dispatch m)
(cond ((= m 0) x)
((= m 1) y)
(else (error "Argument not 0 or 1"))))
dispatch)
(define (frst p) (p 0))
(define (snd p) (p 1))
```

This is a working pair data structure that is implemented only using functions. Function `pair`

is used to make a pair, and `frst`

selects its first item, and `snd`

selects its second item.

```
;; 1
(fsrt (pair 1 2))
;; 3
(snd (pair 2 3))
```

In *exercise 2.4*, an alternative way of implementing pair is given as follows.

```
(define (pair x y)
(lambda (m) (m x y)))
(define (frst p)
(p (lambda (a b) a)))
(define (snd p)
(p (lambda (a b) b)))
```

If you have no problem understand these, then take a look at *exercise 2.6*:

In case representing pairs as procedures wasn’t mind-boggling enough, consider that, in a language that can manipulate procedures, we can get by without numbers (at least insofar as nonnegative integers are concerned) by implementing 0 and the operation of adding 1 as

```
(define zero (lambda (f) (lambda (x) x)))
(define (add-1 n)
(lambda (f) (lambda (x) (f ((n f) x)))))
```

This representation is known as “Church numerals”, after its inventor, Alonzo Church, the logician who invented the [lambda] calculus.

Define

`one`

and`two`

directly (not in terms of`zero`

and`add-1`

). (Hint: Use substitution to evaluate`(add-1 zero)`

). Give a direct definition of the addition procedure`+`

(not in terms of repeated application of`add-1`

).

To be honest, this really made me want to vomit. But hold it back, maybe we can learn a bit of this so called lambda calculus first, and then revisit this problem.

I found a great talk about this topic, and I highly recommend you watch the video several times until you understand most of the things in the talk, and remember to have pen and paper at hand when you do so.

PART I

PART II

If you understand this talk, exercise 2.6 will become trivial and obvious to you.

I now will summarize the talk here.

# Lambda calculus syntax

First let’s take a look at the syntax of lambda calculus. I think it’s easier to explain by examples.

```
;; a function that takes a and returns a
λa.a
;; equivalent form in scheme
(lambda (a) a)
```

```
λa.bx
;; equivalent form in scheme
(lambda (a) (b x))
```

```
(λa.b)x
;; equivalent form in scheme
((lambda (a) b) x)
```

```
λa.λb.x
;; equivalent form in scheme
(lambda (a) (lambda (b) x))
;; This can also be shortened to
λab.x
```

```
λa.bcx
;; equivalent form in scheme
(lambda (a) ((b c) x))
```

# Birds

Let’s now take a look at some important functions. They are all named after birds.

## Idiot Bird

The first one is idiot bird or *I* for short. As its name says, it is not that smart. So it just returns what it takes. Pretty straightforward.

Let’s implement it in Scheme.

```
(define I
(lambda (a) a))
```

## Mocking Bird

This one is pretty interesting. It takes a function, and calls it on itself.

```
(define M
(lambda (f) (f f)))
```

What is `M(I)`

?

It’s `(I I)`

which is just `I`

.

And what is `(M M)`

?

Uh-oh, it is (M M) which is (M M) which is (M M) … so it never ends.

## Kestrel

The *kestrel* takes *a* and *b* then returns *a*.

```
(define K
(lambda (a) (lambda (b) a)))
```

This is the built-in function in Haskel, called `const`

. Why `const`

? Let’s say if we call `K`

with 5. This will return a new function, that no matter what you call it with, it will always return 5. Hence the name `const`

.

Now the fun part.

`K I x = I`

Each side of the equation is a function, so we can do the following:

`K I x y = I y`

We add `y`

to both sides. Since `I y`

always returns y, we will then get

`K I x y = y`

.

If we see `K I`

as one function, then what `K I`

does is that it takes `x`

and `y`

then returns `y`

.

So `K I`

is opposite to `K`

.

This is actually not hard to understand.

As we already know, if you call `K`

with only one parameter `x`

, it returns a *constant x function*. So `K I`

will return a function that will always return `I`

. So `K I a = I`

, then call it with `b`

will get `K I a b = I b = b`

.

So we just derived `Kite`

.

## Kite

```
(define KI
(lambda (a) (lambda (b) b)))
```

This is the opposite of Kestrel.

Now let’s look at a new bird: *Cardinal*.

## Cardinal

`Cardinal`

takes a function and two parameters, but calling them in different order.

```
(define C
(lambda (f)
(lambda (a)
(lambda (b) ((f b) a)))))
```

Let’s see an example. What is `C K I M`

?

`C`

takes in a function `K`

and two parameters `I`

and `M`

and calles them in different order which is `K M I`

= `M`

.

Emm, so `C K I M`

= `M`

, if we see `C K`

as a new function. Then `C K`

is `KI`

! You can type in the scheme code and prove this yourself.

OK, I think we have introduced enough birds, and this post is getting too long so I will stop here. In part II, we will continue and talk about what is Church Encoding. And then get back to our SICP exercise.

Stay tuned!
